The Good news is… the first revenue for the schnabel arrived and it fit well on the new 12" long deck. It is a 500 ton Nuclear reactor pressure vessel.
The Bad news is… It hit the ground on the first curve section leaving the yard.
Back to the drawing board to figure out a fix. I’m thinking about raising the deck by drilling holes higher on the lifting arm. I’m also thinking that the schnabel would benefit from some weight being added to the trucks. Another idea I am toying with is creating a new pivot point that will allow the loaded deck to swing with a curve.
2 Likes
Todd,
Is the drop due to the need of having the connectors loose to navigate around the curves? I wonder if a tight Lazy Susan approach might work? It might help keep the car from leaning into the curve.
All connectors are tightened then loosened just enough to allow for an easy swing.
In the first photo I just posted you will see a large washer that is keeping the rear of the lifting arm from lifting up but I do not think it is needed.
Where do you think the lazy susans would go?
Keep going !
You got about a years worth of detail that you can add …or…you could just run it like it is!
So from what I’m seeing here it appears to me the weak point is within the belly. If the tank/generator(?) is a permanent load then I think I would stiffen up the two ends by running a metal support through the middle.
Thanks for the ideas. The belly is actually pretty stiff. There is a rod that passes through the lifting arm and through the deck (belly) so it is removable.
The schnabel made it through this curve with the short connecting piece on. What happened here is the longer load 12" overhangs the track so much that it caused both ends of the schnabel to tip in.
I have seen photos of the real deal with a connecting support where you would put the rod, on top of the load as well as the bottom.
I think I need to add weight to the lower trucks and then see if I can tighten the screws that hold what I call, the bridge that the cab sits on. I have some wide fender washers under there and maybe adding a few more towards the edges will prevent the bridge from tipping?
Hmmm
Todd, though my first thought was as Rooster presented, I don’t think that will help as the over hang weight is more then the body of the two car ends can support.
I would use modeling license and modify the lift arm ends:
To accomplish this I would cut between the red and black, then in-line with the yellow stripe on both lift arms. With those sections removed use the swivels Bill showed to re-secure the cut off areas back to the lift arms. By relocating the swivel point the arms will stay more in line with the track and the load will stay more in line with the car thus limiting some of that drastic over hang. You have to compensate for the unrealistic curves we all have to deal with.
Unrealistic yes but only noticeable on curves and I think the wow factor of the car will compensate for the mod. JMHO YMMV
